Horizontal Machining Centres

4-axis Horizontal Machining Centre
Quaser MK603H / 10

2002 with Fanuc 18MV control, twin 500 x 500 pallets, NC-Rotary table 0.001°, Travels: X 710 mm, Y 610 mm, Z 610 mm, Spindle: BIG PLUS BT40, 11/15 KW, 10000 rpm; 60 station ATC, used for approx 6000 hours, BARGAIN PRICE!

Click here to Contact Us for more details



Makino MCF 4025 Horizontal Machining Centre with Boring Spindle - XXL Capacity with µm precision

Year 2001 with Fanuc 15M and Professional 3 2 pallets 1600 x 3000 mm. Pallet load max. 13500 kg. B-Axis NC rotary table 0.0001°. Travels: X 4050 mm. Y 2500 mm. Z 2000 mm. W 300 mm. Spindle taper HSK-A 100. Spindle drive 22/30 KW. Spindle speeds to 4000 rpm. 240 station tool magazine. Coolant through the spindle 30 bar. Measuring probe. Linear scale feedback 0.1 µm. Swarf conveyor. (NO CE MARKING). TWO machines available. Linear pallet system is NOT for sale

Proposal Number: MH-5597
Click here to Contact Us for more details



Mazak H1000 Palletech

Year of manufacture 1998. Mazatrol M Plus CNC control. Palletech linear pallet system with 9 pallets 1000 x 1000 mm. Working traverses: X 1640 mm, Y 1220 mm, Z 1000 mm. Table as NC-Rotary table - 4th Axis - B-Axis 0.001°. Spindle taper : CAT 50. Spindle drive motor rating 30 KW. Spindle speeds to max. 4000 rpm. Automatic tool changer . Tool magazine 240 ATC. X,Y,Z axes with Linear scales , B rotary inductosyn - for very high accuracies. Renishaw probe

Proposal Number: MH-5496
Click here to Contact Us for more details

4-axis CNC Horizontal Machining Centre
TOSHIBA BMC-1000

2001. Tosnuc 888 control 2 x pallets 1000 x 1000 mm. Table B-Axis 0.001°. Traverses 2000 x 1500 x 1200 mm. ISO 50. 5000 rpm. 90 tool ATC.

Proposal Number: MH-5271
Click here
and receive a full specification by email

FMS system comprising 2 Horizontal Machining Centres
CINCINNATI T10 machines

12 of 500 x 500 pallets, full B axis 0.001 degree indexing, Traverses 813 x 660 x 660; spindle taper ISO 50, 11 / 18 kW, 6000 rpm, 120 station tool changers. Machines were completely overhauled in 2003 complete with the new controls. Machines can be sold in various configurations. Call to discuss.

Proposal Number: MH5176-5177

Click here
and receive a full specification by email

CNC Horizontal Machining Centre with Pallet Changer
HELLER BEA 07

1985; uni Pro NC 80-C control; 2 pallets 400 x 500 mm; Pallet load capacity 300 kg; Table indexing 1°; Travels X 630, Y 500, Z 560 mm; Spindle drive motor 15 KW; Spindle speeds 45 - 6000 rpm; Tool taper ISO 40; 40-station tool magazine.

Proposal Number: MH-4031

Click here
and receive a full specification by email

CNC Horizontal Machining Centre with Pallet Changer
MATSUURA ES450H

1997; Fanuc 18iM control; 2 pallets 300 x 300 mm; Traverses X 450 mm, Y 400 mm, Z 400 mm; 1° table indexing; Spindle speeds 50 - 10000 rpm; Spindle motor rating 7.5/5.5 KW; Tool taper MAS BT 40; 30 station tool magazine; Swarf Conveyor; Coolant through the spindle.

Proposal Number: MH-4482

Click here
and receive a full specification by email
